| Place of Origin: | China |
| Brand Name: | Anchorwill |
| Certification: | 3C |
| Model Number: | AKS620 |
| Applicable standards | GB14048.6-2008(idt IEC 60947-4-2:2002) |
|---|---|
| Motor power | 18A-1000A(4-500kW) |
| Key lock and function selection | Partial or full locking of keys, define the function range of some keys to prevent misuse |
| Protection and monitoring | Short-circuit, over-voltage, under-voltage, overload, phase failure, phase sequence, over-current, grounding, current imbalance Motor temperature protection, repeat start time |
| Adjustable starting torque | 30%-80%(direct starting torque) |
| Number of functions | >145 |
This starter is specifically designed for coal mines containing explosive gas (A-burning) and coal dust. It enables remote control of soft starting, stopping, and reversing operations for mining explosion-proof three-phase squirrel-cage asynchronous motors. The system provides comprehensive protection for both the motor and its wiring, featuring:
Leakage lockout: Built-in leakage detection using DC detection method, eliminating the need for external leakage plug-in components.
Bypass monitoring: Provides real-time monitoring in both direct start and soft start states for comprehensive motor protection.
Communication function: Standard configuration includes communication components with support for customization and multiple standard bus protocols. Factory default setting uses Modbus-R Tu protocol for easy group control technology implementation.
